Display Cast Pro

Managed digital signage player for HDMI displays with media content playback, web mode, and USB-C peripheral support.

• Up to 4K / 60 FPS Video Content Support
• YouTube Mode
• USB-C Peripheral Support
• UniFi WiFi Auto-Link / Ethernet Connectivity
• PoE In or USB-C Power
• Pair with HDMI display

Note. USB-C power adapter and HDMI cable not included. Does not support Protect camera streaming. Use Protect Viewport to view Protect camera feeds on an HDMI display.



Transform Any HDMI Display into a Smart Signage Solution

The Display Cast Pro is a managed digital signage player that connects to any HDMI-compatible display, instantly converting it into a smart, centrally managed signage endpoint. Ideal for retail, hospitality, and corporate environments, it simplifies content delivery across multiple locations.



Flexible Installation

Measuring 123 x 52 x 31 mm without the mount, the Display Cast Pro's compact form factor allows for discreet installations. Its design accommodates various mounting scenarios, ensuring it fits seamlessly into different environments.



Seamless Integration with UniFi Connect Ecosystem

Managed through the UniFi Connect platform, the Display Cast Pro ensures streamlined device management and content scheduling. Administrators can remotely configure settings, deploy content, and monitor performance, all from a centralised interface.



Technical Specs

Overview

Dimensions

Without mount: 123 x 52 x 31 mm (3.5 x 2.1 x 1.2")
With mount: 125.1 x 56.3 x 40.8 mm (3.6 x 2.1 x 1.4")

NDAA Compliant

Yes

Mechanical

Weight

Without mount: 240 g (5.8 oz)
With mount: 260 g (9.2 oz)

Pole Mount Diameter

1—2" (25—50 mm)

Hardware

Processor

Octa-core CPU including (2) ARM® Cortex®-A78 and (6) ARM® Cortex®-A55
Integrated Mali-G57 GPU

Power

(1) GbE RJ45 port (Power input)
(2) USB Type-C port (Power input)

Connectivity

WiFi 2.4G, BW 20/40 MHz
WiFi 5G, BW 20/40/80 MHz

WiFi Standards

802.11 a/b/g/n/ac/ax

Buttons

(1) Factory-reset

LEDs

System: White/blue

Ambient Operating Temperature

0 to 40° C (32 to 104° F)

Ambient Operating Humidity

20 to 90% noncondensing

Certifications

CE, FCC, IC, Wi-Fi CERTIFIED

Software

Management Application

UniFi Connect Web: Version 3.14.6 and later
UniFi Connect iOS™ and Android™: Version 2.18.1 and later
